Samsung Smart signage Touch screen Series

32" 43" 55" Interactive Display QMR-T

LH32QMRTBGCXXT, LH43QMRTBGCXXT, LH55QMRTBGCXXT

  • โซลูชันระบบสัมผัสแบบครบวงจรสำหรับทุกสภาพแวดล้อม
  • ประสบการณ์สัมผัสอันทรงพลัง
  • ทัศนวิสัยดีขึ้นแม้อยู่ในที่ที่มีแสงแดดส่องถึง

Display

  • Diagonal Size 32"
  • Panel Type New Edge, 60Hz
  • Resolution 1,920 x 1,080
  • Pixel Pitch (HxV) 0.36375 x 0.36375 (mm)
  • Brightness (Typical) 400(without glass), 300(with glass)
  • Contrast Ratio 5000:1(without glass)
  • Viewing Angle (H/V) 178/178
  • Response Time 8ms
  • Color Gamut 72%
  • Glass Haze 2% (without Glass)
  • H-Scanning Frequency 30 ~ 81kHZ
  • Maximum Pixel Frequency 594MHz
  • V-Scanning Frequency 48 ~ 75HZ
  • Contrast Ratio (Dynamic) Mega DCR

Optional Feature

  • Touch Yes
  • Mount WMN4070SE
  • Stand STN-L3240F

Connectivity

  • HDMI In 2
  • DP In Yes
  • DVI In N/A
  • Tuner In N/A
  • USB 2
  • Component In N/A
  • Composite In N/A
  • RGB In N/A
  • IR In Yes
  • HDBaseT In No
  • Audio In No
  • Audio Out Stereo Mini Jack
  • Video Out Yes
  • Power Out N/A
  • RS232 In Yes
  • RS232 Out Yes
  • RJ45 In Yes
  • RJ45 Out No
  • WiFi Yes
  • 3G Dongle No
  • Bluetooth Yes

Internal Player (MagicInfo)

  • MagicInfo Daisychain Videowall Support Yes

Power

  • Power Supply AC100-240V 50/60Hz
  • Power Consumption (Off Mode) N/A
  • Power Consumption (On Mode) 72 W
  • Power Consumption (Sleep Mode) 0.5 W

Eco

  • Energy Efficiency Class N/A

Dimension

  • Set Dimension (WxHxD) 744.4 x 444.6 x 48.2 mm
  • Package Dimension (WxHxD) 872 x 565 x 133 mm

Touch

  • Touch Technology Capative

Weight

  • Set Weight 8.3 kg
  • Package Weight 11.1 kg

Certification and Compliance

  • EMC Class B
  • Safety 60950-1

Operation Conditions

  • Temperature 0℃~ 40℃
  • Humidity 10 ~ 80%, non-condensing


Mechanical Specification

  • VESA Mount 200 x 200 mm
  • Bezel Width N/A
  • Frame Material Non-Glossy


General Feature

  • External Memory Slot N/A
